Ritchey Outback Frameset - Winter Sage

Sale price £1,400.00

Tax included

Shipping calculated at checkout

Size

We Say...

We thought the Ritchey Outback couldn't get any better right?

Wrong! Now it has cable routing on the down tube, Dropper routing, dynamo routing and Green is back baby!

Plus they have kept everything that made it great, supple Ritchey Logic tubing, a compliant carbon fork and a geometry like no other!

Robbie

They Say...

Tom Ritchey rides about 10,000 miles (16,000 km) per year, mostly off-road. Combine that with more than 50 years of crafting bicycles, and it’s no wonder that the Outback is an icon in the gritty world of gravel and adventure cycling.

Standout features for this edition of the 2025 Outback include internal routing for a dropper post, a rack mount on the fork crown, and internal dynamo routing. Aurora and Winter Sage colorways offer riders more options to style their ride beyond the bike’s existing practical and adaptable features, but the “big” news is, this Outback also comes in size XXL.

Bikepacking, road and off-road, you name it…the Ritchey Outback is designed to do it all.



Features:

  • Includes Ritchey Adventure Fork with multipurpose mounts
  • Accepts 700c x 48mm or 650b x 2.0in tires
  • Features rack and fender mounts

(*Only the Granite & Snow color Outback frame features this new flat mount design)

Frame
Material- heat-treated, triple-butted Ritchey Logic steel tubing - TIG welded
Ultra-light forged and machined straight 1-1/8" headtube
Electrophoretic Deposition (ED Coat) treated for corrosion resistance
Seat tube clamp size- 28.6mm (2.5Nm max for derailleur clamps and chain guides)
27.2mm seat tube with integrated seat collar (max torque setting: 6Nm)
Bottom bracket- 68mm - English threaded
142mm spacing (12mm alloy thru-axle included)
Crankset min/max ring size - single36 to 46t / double: 46/30t to 50/34t
Can accommodate 1X or 2X chainrings
Chainline- 49mm
Not compatible with Direct Mount standard and related components (T-Type derailleurs and cassettes)
Bottle cage mounts-
Rack and fender mounts
Stealth wire routing for semi-wireless Di2 groupsets
DSP internal (seat tube only) routing available
External cable routing
WCS headset included (upper IS42/28.6 - 16mm stack height | lower IS42/30)
Replaceable stainless-steel derailleur hanger

Fork
New Ritchey Carbon Adventure Fork with multi-purpose, rack and fender mounts
1-1/8" straight steerer with integrated 45-degree crown race
Steerer length300mm
Fork length390mm
Axle-crown393mm
Rake/Offset50mm
100mm spacing (12mm alloy thru-axle included)
Fork max payload3kg per side
30mm maximum spacers below stem

Tire Compatibility
Wheel and tire compatibility- 700 x 48mm or 650 x 2.0in (depending on tire/rim manufacturer)
Frame spacing- 58mm
Fork spacing- 60mm

Brake Compatibility
Flat-mount brakes front and rear140mm (160mm max - adaptors available separately)
Frame flat-mount bracket height10mm
