They Say...
One of the first gravel-specific bikes released, the Curve GXR model has been around since well before gravel became cool. Now, with wider tyre clearance, improved mounting options and UDH compatibility, the latest version of our Swiss Army Knife of bikes is more versatile than ever.
We have been ahead of the Curve when it comes to gravel, and the GXR has years of adventure cycling experience woven into its DNA. The Curve titanium GXR has been tested heavily on gravel adventures worldwide. Across South America, New Zealand, Switzerland, Swaziland, and more, the Curve squad has traversed the globe on this magnificent bicycle.
Originally a playful jab at the bike industry's bike naming terminologies, the name “Kevin” soon caught on, and we couldn’t resist making it official. Kevin, the reliable Aussie all-rounder, is here to stay as a permanent nickname for our beloved GXR.
Frame - Titanium Curve GXR4. At the core of each frame is a 3Al - 2.5V Grade 9 aerospace grade titanium tubeset. This grade is optimal for bicycle frames and chosen for its fine balance of stiffness, compliance and durability.
Fork - Curve Ride 415 VGM carbon fork
Headset - Curve Integrated 42/52 mm semi-internal
Seat Clamp - Curve Alloy 31.8 mm
Other - Curve Cocky Headbadge, 12 mm Front & Rear Axles, spare SRAM UDH derailleur hanger
SRAM Rival E1 GX T-Type
Shifter/Levers - Rival E1 AXS 1x12 sp - LHR / RHF
Brakes - Rival Flat Mount Disc // Centrelock Rotors 160 mm
Crank - Rival E1 WIDE DUB - 38t | XXS-SM: 165 mm | M: 170 mm | LG–XXL: 175 mm
Bottom Bracket - T47 DUB internal 85.5 mm
Rear Derailleur - GX T-Type 12 sp
Cassette - XS 1275 T-Type 10-52t
Chain - GX T-Type 12 sp
G4T 45 - 700C
Curve carbon all-road wheels:
- 21 mm internal, 28 mm external, 45 mm deep
- Hub: DT Swiss 350 24H Centrelock
- Spokes & Nipples: Sapim CX Ray spokes and brass nipples
Bars - Curve Walmer Bar
XXS: 43 | XS-LG: 46 | XL–XXL: 50
Stem - Zipp Service Course
XXS–S: 70 mm | M–L: 80 mm | XL-XXL: 90 mm
Seatpost - Zipp SC 0 Setback 27.2 mm
Saddle - Prologo Dimension 143
Tyres - Vittoria Terrano Mixed T50 - 700c x 50 mm
Bar Tape - Curve black anti-shock
Please Note: Spec subject to change according to availability
